GB/T DC Charging Connector

Detail

— Fast charging

— Suitable for charging piles in China

— Vehicle plug with built-in latch and protective cover








80A125A200A250A--
Voltage750V /1000VAC750V /1000VAC750V /1000VAC750V /1000VAC--
Current80A125A200A250A--
I.R>2000MΩ>2000MΩ>2000MΩ>2000MΩ--
Operate Temperature-40°C ~   +50°C-40°C ~   +50°C-40°C ~   +50°C-40°C ~   +50°C--
Withstand Voltage3500V AC3500V AC3500V AC3500V AC--
IP ClassIP55IP55IP55IP55--
Flame classUL94-V0UL94-V0UL94-V0UL94-V0--
Mating Force<140N<140N<140N<140N--
Mating Cycles>10000>10000>10000>10000--
Cable lengthcustomizecustomizecustomizecustomize--
Cable colorblackblackblackblack--
Cable O.D33.5±136.5±137.5±140±1--
Cable specification20mm²35mm²50/70mm²70/80mm²--
